Laboratory Furnace

Prominent & Leading Manufacturer from Gurgaon, we offer bottom loading furnace, vertical tube furnace, furnace and high temperature muffle furnace.

Bottom Loading Furnace

Bottom Loading Furnace
  • Bottom Loading Furnace
Get Best Quote
Approx. Price: Rs 30,000 / PieceGet Latest Price

Product Details:

Max Power9 kw
Working VoltageAC 380v three phases 60/50 hz( or according to your requirement)
Heating ElementMoSi2 heating elements
Temperature Accuracy+/-1.C
Heating Rate0-10.C/min (suggestion less than equal to 10.C)
Temperature Control30 staps programmable and PID automati ccontrol
Inside Chamber Size200x200x200 mm
Standard working Temperature1700C (continuous)
Maximum working Temperature1700C (less than 3 Hrs)

The single zone, high temperature, Bottom Loading Furnace is capable of operating at temperatures up to 1650oC in air. The furnace utilizes 1800oC molydisilicide heating elements positioned on three sides of the internal chamber. The furnace utilizes an energy efficient insulation package consisting of graded ceramic-fiber, high temperature insulation. It is an ideal tool for materials annealing and sintering.

Standard size:

  • Sample Size: 200x200x 200mm (8"x8"x8")
  • Model: Chamber size(VVXHxDmm)
  • IFC-1600BL: 150x150x 150mm (6"x6"x6")
  • IFC-1600BL: 150x150x 200mm (6"x6"x8")
  • IFC-1600BL: 200x200x 200mm (8"x8"x8")
  • IFC-1600BL: 200x200x 300mm (8"x8"x1 T)
  • IFC-1600BL: 250x250x 300mm (10"x10"x12)
  • IFC-600BL: 300x300x 400mm (12"x12"x16")
  • IFC-1600BL:400x400x 400mm (16"x16"x16")
  • IFC-1600BL: 500x500x 500mm (20"x20"x20")
Request
Callback
Yes! I am Interested

Vertical Tube Furnace

Vertical Tube Furnace
  • Vertical Tube Furnace
Get Best Quote
Approx. Price: Rs 50,000 / PieceGet Latest Price

Product Details:

MaterialStainless Steel
Automation TypeAutomatic
BrandLabsol
Standard Working Temperature1150
Maximum Working Temperature1200
Max Power2.5KW
Working VoltageAC 220V 50HZ 1phase

Under precious guidance of our skilled professionals, we are engaged in offering a wide range of Vertical Tube Furnace. Owing to its remarkable quality, the offered product is widely demanded in the market. These chambers are manufactured by our experienced professionals using premium quality raw material and progressive technology. Moreover, we check that entire range on various parameters to make a flawless dispatch from our clients' end.

Features:

  • Excellent resistance against corrosion
  • Durability
  • Sturdy construction


Model Overview:


Tube furnace dimensionInner 35 mm, outer 45 mm
Standard Working Temperature1150
Maximum Working Temperature1200
Profile controllerRam sock Theristor drive 8 Programme
Temperature accuracy± 1
Heating zone12”
Total length of the tube24”
Gas Flow Provision3 Rota meter for gas flow(Programmable
time & temperature)
Working VoltageAC 220V 50HZ 1phase
Max. Power2.5KW
Quantity1 unit
Request
Callback
Yes! I am Interested

Furnace

Furnace
  • Furnace
Get Best Quote
Approx. Price: Rs 23,000 / PieceGet Latest Price

Product Details:

MaterialStainless Steel
Automation TypeAutomatic
BrandLabsol
Display TypeDigital
UsageIndustry
Application Laboratory

A Furnace is a device used for high-temperature heating. The name derives from Greek word fornax, which means oven.

In American English and Canadian English usage, the term furnace on its own refers to the household heating systems based on a central furnace (known either as a boiler, or a heater in British English), and sometimes as a synonym for kiln, a device used in the production of ceramics. In British English, a furnace is an industrial furnace used for many things, such as the extraction of metal from ore (smelting) or in oil refineries and other chemical plants, for example as the heat source for fractional distillation columns.

Request
Callback
Yes! I am Interested

High Temperature Muffle Furnace

Approx. Price: Rs 35,000 / PieceGet Latest Price

Product Details:

Minimum Order Quantity1 Piece
Melting MaterialAluminium
Power SourceElectric
Type Of FurnaceFix
Country of OriginMade in India

We are manufacturers of Muffle Furnace in India since last two decades. We strongly believe in the principle of quality first and everything else to follow, which reflects in our products, which are renowned for long trouble free services in various hospitals and research institutes across India and abroad. We have been highly acclaimed by the experts from various food and pharmaceutical industries, hospitals and research institutes for our innovative range of muffle furnace and customized solutions to meet specific research applications. Over a short period of time Labsol brand have been established as a leading exporters of Muffle Furnace in India, catering to South Asian, African and European Markets. Beside the regular exports we are also catering to our domestic market and are suppliers of our Muffle Furnace to various laboratories, institutes, hospitals, nursing homes and research faculties. Page 2 Light weight with ceramic wool insulation (instead of Brick insulation). The outer casting is made of double walled thick PCRC sheet, duly painted with attractive stove enamel. Heating elements are made of Kanthal A1 wire and backed by high temperature cerwool insulation, which avoids loss of energy. The temperature control unit consists of micro-processor based PID controller cum indicator. The apparatus is complete with one pyrometer, thermocouple, silver thermal fuse, and main lead with power plug to work on 220/230Volts AC or 400/440 Volts AC.
Request
Callback


Additional Information:

  • Item Code: LBS-MF-MT
  • Delivery Time: Within 3-4 weeks from the date of receipt of your purchase order
